Description
The 15 mm (1/2″) motorized ball valve with manual override is a high-quality electrically actuated valve designed for reliable automatic flow control in water treatment, irrigation, industrial, commercial, and domestic applications.
Manufactured from durable 304 stainless steel, this motorized ball valve provides dependable operation and excellent corrosion resistance. The integrated manual override allows the valve to be operated manually during power failures, commissioning, servicing, or maintenance.
The full-port ball design provides efficient flow with minimal pressure loss, making it suitable for reverse osmosis systems, water filtration equipment, dosing systems, borehole installations, irrigation, and general fluid control applications.
Features:
- 15 mm (1/2″) BSP threaded connections.
- Durable 304 stainless steel valve body.
- Electrically actuated motorized valve.
- Manual override for emergency and maintenance operation.
- Full-port ball design for efficient flow.
- Low power consumption.
- Quiet and reliable operation.
- Long service life.
- Corrosion-resistant construction.
- Suitable for automatic flow-control systems.
- Compact design for easy installation.
- Suitable for a range of water-treatment applications.
Specifications:
- Product type: Motorized ball valve.
- Nominal size: 15 mm (1/2″).
- Connection: BSP threaded.
- Valve material: 304 Stainless steel.
- Actuator type: Electric motorized actuator.
- Manual override: Yes.
- Valve design: Full port.
- Pressure rating: 1.6 / 2.5 MPa.
- Maximum pressure: Up to 25 bar, depending on operating conditions.
- Voltage: 220 V.
- Input signal: 4–20 mA.
- Output signal: 4–20 mA.
- Medium temperature: 0°C to 90°C.
- Ambient temperature: -10°C to 60°C.
- Protection rating: IP65.
- Media: Water, air, light oils, and compatible non-corrosive liquids.
- Duty cycle: 50%.
Applications:
- Reverse osmosis systems.
- Water purification plants.
- Water filtration systems.
- Borehole water systems.
- Irrigation systems.
- Pump automation.
- Chemical dosing systems.
- Commercial water-treatment installations.
- Industrial process control.
- HVAC systems.
- Swimming pool water-treatment systems.
- Automatic water flow-control systems.
Why choose the 15 mm (1/2″) motorized ball valve?
- Automatic flow control: Allows the valve to be integrated into automated water-treatment and control systems.
- Manual override: Provides a convenient method of operating the valve when power is unavailable or during maintenance.
- 304 stainless steel construction: Offers excellent durability and corrosion resistance.
- Full-port design: Helps maintain high flow rates while minimising pressure loss.
- Wide application range: Suitable for water treatment, irrigation, pumping, filtration, and general fluid-control applications.
- Reliable operation: Designed for consistent and dependable valve actuation.
- Compact installation: The 15 mm (1/2″) connection size makes it suitable for smaller pipework and compact equipment.
- IP65 protection: Provides protection against dust ingress and water jets, making it suitable for many demanding installation environments.
