Description

The Pressure Gauge 0-25 Bar Panel Mount is a precision pressure measuring instrument designed to accurately monitor water, air, steam, and other compatible non-corrosive fluids in commercial, industrial, and water treatment systems. Its rear entry (panel mount) connection makes it ideal for installation in control panels, filtration skids, pressure vessels, and equipment where the gauge is mounted through a panel for easy viewing.

With a 0 to 25 bar pressure range, 63mm stainless steel dial, and 1/4″ BSP rear connection, this pressure gauge is ideal for high-pressure applications such as Reverse Osmosis systems, booster pumps, hydraulic systems, and industrial processing equipment. It provides accurate pressure readings to help identify leaks, pressure fluctuations, blockages, and other system issues before they affect equipment performance.

Features:

• Measures pressure from 0 to 25 bar.
• Rear entry (panel mount) connection.
• Large, easy-to-read 63mm dial.
• Stainless steel case for excellent corrosion resistance.
• High accuracy (Class 1.6).
• Suitable for water, air, steam, and compatible non-corrosive fluids.
• Designed for commercial and industrial applications.
• Standard 1/4″ BSP connection.
• Ideal for installation in control panels and equipment enclosures.
• Low maintenance and long service life.

Specifications:

• Pressure Range: 0 to 25 bar (0 to approximately 363 psi).
• Connection Size: 1/4″ BSP.
• Mounting Type: Panel Mount (Rear Entry).
• Dial Size: 63mm (2.5″).
• Accuracy Class: 1.6% Full Scale.
• Case Material: Stainless Steel.
• Operating Temperature: -20°C to +60°C.

Applications:

• Reverse Osmosis systems.
• Water treatment plants.
• Water filtration systems.
• Pressure vessels.
• Booster pump systems.
• Industrial control panels.
• Hydraulic systems.
• Borehole water systems.
• Irrigation systems.
• Commercial process equipment.
• Compressed air systems.
• Steam systems.
• Plumbing systems.
• Commercial and residential water systems.

Why Choose the Pressure Gauge 0-25 Bar Panel Mount?

• Delivers accurate and reliable pressure monitoring for high-pressure systems.
• Rear entry design is ideal for neat installation in control panels and equipment housings.
• Helps detect pressure loss, leaks, blockages, and abnormal operating conditions before they damage equipment.
• Durable stainless steel construction provides long-lasting performance in demanding environments.
• Large 63mm dial offers clear, easy-to-read pressure measurements.
• Standard 1/4″ BSP connection ensures compatibility with a wide range of water treatment and industrial equipment.
• Suitable for water, air, steam, and other compatible non-corrosive fluids.
• Helps protect pumps, membranes, pressure vessels, and other critical equipment by ensuring systems operate within their recommended pressure range.
