Description

The UVC Pro UV Reactor 32W PRO-08 is a complete ultraviolet water-treatment unit designed to provide UV-C microbial treatment for compatible water-treatment systems with flow rates of up to 30 litres per minute.

The system uses a 32W UVC Pro UV lamp inside a 304 stainless-steel UV reactor. As water passes through the reactor, it is exposed to UV-C radiation, which helps inactivate microorganisms in the treated water.

UV treatment is a chemical-free water-disinfection process and does not add chemical disinfectants to the treated water. UV treatment does not remove suspended solids, dissolved minerals, salts, iron, hardness or other non-microbial contaminants. Therefore, use appropriate pre-treatment where required.

The PRO-08 is supplied as a complete UV reactor unit and is designed for compatible domestic, borehole and small commercial water-treatment applications.

Features:

• Complete UVC Pro PRO-08 UV reactor.
• 32W UV lamp.
• UV-C microbial treatment.
• Flow range of 23–30 L/min.
• 304 stainless-steel reactor construction.
• ½” male NPT inlet and outlet connections.
• Maximum working pressure of 8.5 bar.
• Compact inline design.
• Chemical-free UV disinfection process.
• Designed for compatible domestic and small commercial water-treatment systems.
• Suitable for compatible borehole water-treatment applications.
• Uses dedicated UVC Pro replacement components.
• Replacement lamp and other compatible components are available separately.

Specifications:

• Product type: UV water treatment reactor.
• Model: UVC Pro PRO-08.
• UV lamp power: 32W.
• UV lamp configuration: 1 × 32W UV lamp.
• Flow range: 23–30 L/min.
• Flow range: 1,380–1,800 LPH.
• Reactor material: 304 stainless steel.
• Inlet connection: ½” Male NPT.
• Outlet connection: ½” Male NPT.
• Maximum working pressure: 8.5 bar.
• UV treatment: UV-C microbial treatment.
• Application: Water treatment and UV disinfection.
• Installation: Inline.
• Product supplied: Complete UVC Pro PRO-08 UV reactor.

Applications:

• Domestic water treatment.
• Drinking-water treatment.
• Borehole water treatment.
• Point-of-entry UV treatment.
• Household water-treatment systems.
• Small commercial water-treatment systems.
• UV microbial treatment.
• Compatible water-purification systems.
• Applications requiring UV treatment within the PRO-08 flow range.

Why choose the UVC Pro UV reactor 32W PRO-08?

• Complete UV reactor: Supplied as a complete PRO-08 UV treatment unit.
• 32W UV lamp: Provides the UV-C light source for microbial treatment.
• 23–30 L/min flow range: Suitable for compatible domestic and small commercial applications.
• 304 stainless-steel reactor: Provides a durable chamber for UV water treatment.
• ½” male NPT connections: Suitable for compatible plumbing installations.
• 8.5 bar pressure rating: Suitable for installations operating within the specified maximum pressure.
• Chemical-free treatment: Uses UV-C radiation rather than adding chemical disinfectants to the water.
• Compact design: Suitable for installations where a compact inline UV reactor is required.
• Replacement components available: Compatible UVC Pro components can be replaced as part of ongoing maintenance.

How the UV reactor works:

• Water enters the UV reactor through the inlet.
• Water flows through the reactor chamber around the quartz sleeve.
• The 32W UV lamp produces UV-C radiation.
• UV-C exposure helps inactivate microorganisms as the water passes through the reactor.
• Treated water exits through the outlet and continues to the point of use.

Installation & maintenance:

• Install the UV reactor in the correct direction of water flow.
• Confirm that the plumbing is compatible with the ½” male NPT connections.
• Suitable ½” female fittings are required to connect to the reactor.
• Install suitable pre-filtration before the UV system where required.
• Ensure the incoming water is suitable for UV treatment.
• Keep the flow within the specified 23–30 L/min operating range.
• Do not exceed the maximum working pressure of 8.5 bar.
• Isolate the water and electrical supply before servicing.
• Never operate the UV lamp outside the reactor.
• Never look directly at an operating UV lamp.
• Avoid direct exposure of skin and eyes to UV-C radiation.
• Inspect and clean the quartz sleeve periodically according to water quality and maintenance requirements.
• Replace the UV lamp when required.
• Replace the quartz sleeve if it becomes cracked or damaged.
• Check all connections for leaks after installation.
• Protect the electrical components from water ingress.
• Suitable surge protection is recommended to help protect the ballast and electrical components.

Warranty & electrical safety:

Due to the sensitive nature of electrical products, consumables such as bulbs and ballasts do not carry a warranty. It is recommended that suitable surge protection be installed to help protect the electrical components from voltage fluctuations and electrical surges.
