Description
The Global Water Solutions C2-Lite CAD™ 60-Liter Vertical Pressure Tank is a premium lightweight composite pressure vessel designed to deliver reliable water pressure, superior corrosion resistance, and long-lasting performance. Manufactured by Global Water Solutions (GWS), the C2-Lite CAD™ Series combines the proven technology of steel pressure tanks with the benefits of advanced composite construction, making it the ideal choice for residential, commercial, agricultural, and coastal water systems.
The C2-Lite CAD™ 60L Vertical Pressure Tank (Model: C2B-60LV) features GWS’s patented CAD-2™ (Controlled Action Diaphragm) technology. A premium 100% butyl diaphragm and a precision-moulded polypropylene liner completely separate the water from the compressed air, preventing waterlogging, maintaining excellent water quality, and delivering superior drawdown performance. This innovative design reduces pump cycling, improves energy efficiency, and extends the lifespan of pumps and pressure systems.
Unlike conventional steel pressure tanks, the C2-Lite CAD™ Series is manufactured from continuous-strand fibreglass reinforced with epoxy resin, making it completely resistant to rust and corrosion. Its lightweight construction simplifies installation while providing exceptional durability in harsh environments, including coastal areas, humid climates, and outdoor installations. The no-sweat exterior design also helps minimise condensation.
With its compact vertical footprint and maintenance-free operation, the C2-Lite CAD™ 60L is an excellent choice for borehole systems, domestic pressure boosting, irrigation, water treatment systems, rainwater harvesting, and reverse osmosis installations.
Features:
- 60-Liter vertical composite pressure tank.
- Manufactured by Global Water Solutions (GWS).
- C2-Lite CAD™ Series.
- Model: C2B-60LV.
- Patented CAD-2™ Controlled Action Diaphragm technology.
- Premium 100% butyl diaphragm.
- Precision-moulded polypropylene liner.
- Lightweight fibreglass composite construction.
- Completely corrosion-proof and rust-resistant.
- Weather-resistant for indoor and outdoor installations.
- High-tech spin-welded construction.
- Unique three-piece tank design.
- Quality brass air valve with leak-resistant O-ring seal.
- No-sweat exterior helps minimise condensation.
- Reduces pump cycling and extends pump life.
- Maintains stable and consistent water pressure.
- Factory pre-charged for quick installation.
- Suitable for potable drinking water systems.
- Maintenance-free operation.
- Comprehensive factory testing and international certifications.
Specifications:
- Brand: Global Water Solutions (GWS).
- Series: C2-Lite CAD™.
- Model: C2B-60LV.
- Tank type: Vertical composite pressure tank.
- Nominal capacity: 60 Litres.
- Maximum working pressure: 8.6 Bar (125 psi).
- Factory pre-charge: 1.4 Bar (20 psi).
- Maximum operating temperature: 49°C.
- Minimum operating temperature: -10°C (avoid freezing).
- Internal membrane: 100% butyl CAD-2™ diaphragm.
- Internal liner: Precision-moulded polypropylene.
- Construction: Fibreglass composite with epoxy resin.
- Water connection: 1″ BSPT Male.
- Height: 650 mm.
- Diameter: 421 mm.
- Approximate weight: 8.6 kg.
- Orientation: Vertical.
- Colour: Grey.
- Application: Water pressure boosting and pressure storage.
Applications:
- Borehole water systems.
- Residential pressure booster systems.
- Domestic water supply.
- Irrigation systems.
- Rainwater harvesting.
- Reverse osmosis systems.
- Water treatment and filtration plants.
- Agricultural water supply.
- Coastal properties.
- Hotels, lodges, and guest houses.
- Beach resorts and golf courses.
- Commercial water systems.
Why Choose the C2-Lite CAD™ 60-Liter Vertical Pressure Tank?
- Lightweight composite construction makes handling and installation easier.
- Completely rust-proof and corrosion-resistant design provides exceptional durability.
- Patented CAD-2™ technology delivers superior drawdown performance.
- Complete separation of water and air prevents waterlogging.
- Weather-resistant construction is ideal for indoor and outdoor installations.
- Reduces pump cycling to extend pump and motor lifespan.
- Improves energy efficiency and reduces operating costs.
- No-sweat construction helps minimise condensation.
- Suitable for corrosive, coastal, and high-humidity environments.
- Maintenance-free operation reduces servicing requirements.
- Manufactured by Global Water Solutions to internationally recognised quality standards
