Description
Firstly the Radar ST-70AB float switches operate with all kinds of water tanks and pumps for liquid level control. It can be used for either water tank filling or emptying.
Also levels can be achieved by positioning the 2 weights to give a differential of 50mm to 1000mm.
Thereafter switches electrical connections allow direct connection to single phase equipment. In other words the float can be used with a control panel or starter box on low voltage.
Specifications
- Power supply : 110v/240v, 50/60Hz
- Connection: 1″ G
- Rating: 240v – 7.5A, 110v – 15A
- Connection: 1″ & 3/4″ BSP
- Vertical installation
- Control range 0.2 – 5.0 meters
- Maximum temperature: 60°c
- Supplied with mounting bracket
Advantages of the Radar ST-70AB
- Unique patent device of vent slot, prevents vapor condensing inside switch body in humid environments.
- The switch body is in a good sealed condition,to protect from dust and moisture.
- The solid sinkers maintain a steady equilbrum top rovide precise control
- Multi-purpose design for pumping or drainage either, use terminal A for pumping ,or terminal B for drainage
About Radar
Firstly established since 1966, SHINTUNG ELECTRONICS INDUSTRY COMPANY is the expert in producing all kinds of RADAR brand water pump pressure control switches, liquid level control switches, water tower control switches, sewage water level controllers, and oil level control switches. In other words these switches are ideal for be used in all types of water towers, water tanks, water pumps, water purifying facilities, water treatment systems, and boilers.
RADAR brand has a high reputation in Taiwan, South-East Asia, China, and South America for its reliability. It has successfully helped millions of users solving their problems in liquid level control. In 2003, a wholly-owned subsidiary, FUZHOU SHINTUNG PLUMBING EQUIPMENT COMPANY, was established to extend market in mainland China.
