Description

The pressure gauge 0-25 bar bottom mount is a precision pressure measuring instrument designed to accurately monitor water, air, steam, and other compatible non-corrosive fluids in commercial, industrial, and water treatment systems. Its bottom entry connection makes it ideal for direct installation onto pipelines, pumps, pressure vessels, and filtration equipment where reliable pressure monitoring is essential.

With a 0 to 25 bar pressure range, 63mm stainless steel dial, and 1/4″ BSP bottom connection, this pressure gauge is suitable for high-pressure applications, including Reverse Osmosis systems, booster pumps, pressure vessels, hydraulic systems, and industrial processing equipment. It provides accurate pressure readings that help detect leaks, pressure fluctuations, blockages, and other system faults before they affect system performance.

Features:

• Measures pressure from 0 to 25 bar.
• Bottom entry (lower mount) connection.
• Large, easy-to-read 63mm dial.
• Stainless steel case for corrosion resistance.
• High accuracy (Class 1.6).
• Suitable for water, air, steam, and compatible non-corrosive fluids.
• Designed for commercial and industrial applications.
• Standard 1/4″ BSP connection.
• Easy installation on pumps, pipework, and pressure vessels.
• Low maintenance and long service life.

Specifications:

• Pressure range: 0 to 25 Bar (0 to approximately 363 psi).
• Connection size: 1/4″ BSP.
• Mounting type: Bottom entry (lower mount).
• Dial size: 63mm (2.5″).
• Accuracy class: 1.6% Full scale.
• Case material: Stainless steel.
• Operating temperature: -20°C to +60°C.

Applications:

• Reverse osmosis systems.
• Water treatment plants.
• Water filtration systems.
• Pressure vessels.
• Booster pump systems.
• High-pressure pump installations.
• Borehole systems.
• Irrigation systems.
• Industrial process equipment.
• Hydraulic systems.
• Plumbing systems.
• Compressed air systems.
• Steam systems.
• Commercial and residential water systems.

Why choose the pressure gauge 0-25 bar bottom mount?

• Provides accurate and reliable pressure monitoring.
• Designed for demanding high-pressure commercial and industrial applications.
• Bottom entry connection allows quick and simple installation.
• Helps identify leaks, pressure drops, blockages, and system faults before they cause damage.
• Durable stainless steel construction ensures long service life in harsh environments.
• Large 63mm dial provides clear and easy-to-read pressure measurements.
• Standard 1/4″ BSP connection is compatible with a wide range of equipment.
• Suitable for water, air, steam, and other compatible non-corrosive fluids.
• Helps protect pumps, membranes, pressure vessels, and other critical equipment by ensuring systems operate within the correct pressure range.
