Description

The pressure gauge 0-10 bar panel mount is a high-quality pressure measuring instrument designed for accurate monitoring of water, air, steam, and other compatible non-corrosive fluids in commercial, industrial, and water treatment systems. Installed through a control panel using its rear entry connection, it provides a clean, professional appearance while allowing operators to monitor system pressure at a glance.

With a 0 to 10 bar pressure range, 63mm stainless steel dial, and 1/4″ BSP rear connection, this pressure gauge is ideal for Reverse Osmosis systems, filtration plants, pump panels, irrigation systems, and other pressure-operated equipment. Accurate pressure monitoring helps identify leaks, pressure fluctuations, blockages, and other system issues before they affect performance.

Features:

• Measures pressure from 0 to 10 bar.
• Panel mount with rear entry connection.
• Large, easy-to-read 63mm dial.
• Stainless steel case for corrosion resistance.
• High accuracy (Class 1.6).
• Suitable for water, air, steam, and compatible fluids.
• Durable construction for commercial and industrial applications.
• Standard 1/4″ BSP connection.
• Professional panel-mounted installation.
• Low maintenance and long service life.

Specifications:

• Pressure range: 0 to 10 Bar (0 to approximately 145 psi).
• Connection size: 1/4″ BSP.
• Mounting type: Panel mount (rear entry).
• Dial size: 63mm (2.5″).
• Accuracy class: 1.6% Full scale.
• Case material: Stainless steel.
• Operating temperature: -20°C to +60°C.

Applications:

• Reverse osmosis systems.
• Water treatment plants.
• Water filtration systems.
• Control panels.
• Booster pump systems.
• Irrigation systems.
• Borehole installations.
• Pressure vessels.
• Industrial process equipment.
• Plumbing systems.
• Compressed air systems.
• Steam systems.
• Commercial and residential water systems.

Why choose the pressure gauge 0-10 bar panel mount?

• Provides accurate and reliable pressure monitoring.
• Rear entry design is ideal for professional control panel installations.
• Helps detect leaks, pressure drops, blockages, and system faults.
• Durable stainless steel construction for long-lasting performance.
• Large 63mm dial provides clear, easy-to-read pressure readings.
• Standard 1/4″ BSP connection allows quick and simple installation.
• Suitable for water, air, steam, and other compatible non-corrosive fluids.
• Ideal for residential, commercial, and industrial pressure monitoring applications.
